Second hand icom ic-7800 mkii hf base station transceiver.
Click the image to enlarge

Second Hand Radio equipment

Secondhand Icom IC-7800 MKII HF base station transceiver.

£3,999.00
(£3,999.00 exc. VAT)
£4,499.00
(£4,499.00 exc. VAT)
Fast uk delivery
Worldwide delivery
Out of Stock
0 Reward points
Product code: SH-IC-7800-MKII
Download a pdf document for Secondhand Icom IC-7800 MKII HF base station transceiver.

Want to be notified when this product is back in stock? Complete the form below and we'll send you an email when it is.

Finance Available

Radioworld now offer finance through our partners Close Brothers.

Add the item to your basket in the normal way and at checkout choose to make payment via Finance. You’ll then be taken through to our partners Pay4Later to make your finance application.

Item CostFinance OptionDepositMonthly PaymentsTotal Cost
£4,499.00
12 Months 14.9% APR
£449.90
£387.70
£5,102.32
£4,499.00
18 Months 14.9% APR
£449.90
£258.47
£5,102.32
£4,499.00
24 Months 14.9% APR
£449.90
£193.85
£5,102.32
£4,499.00
36 Months 14.9% APR
£449.90
£129.23
£5,102.32
£4,499.00
48 Months 14.9% APR
£449.90
£96.93
£5,102.32
£4,499.00
12 Months 19.5% APR
£449.90
£403.22
£5,288.57
£4,499.00
18 Months 19.5% APR
£449.90
£268.82
£5,288.57
£4,499.00
24 Months 19.5% APR
£449.90
£201.61
£5,288.57
£4,499.00
36 Months 19.5% APR
£449.90
£134.41
£5,288.57
£4,499.00
48 Months 19.5% APR
£449.90
£100.81
£5,288.57

Click here to recommend this product to a friend

Recommend a friend

Second hand icom ic-7800 mkii hf base station transceiver.

Secondhand Icom IC-7800 MKII HF base station transceiver.


The Second Hand Icom IC-7800 MKII HF Base Station Transceiver is a versatile ham radio that covers all HF bands plus 50MHz. It offers a wide range of transmission modes including SSB, CW, RTTY, PSK31, FM, and AM, with adjustable output power ranging from 5-200W for SSB, CW, RTTY, and PSK31, and 5-50W for AM. The transceiver has a frequency range of 0.1357-0.1378, 1.800-1.999, 3.400-4.099, 6.900-7.499, 9.900-10.499, 13.900-14.499, 17.900-18.499, 20.900-21.499, 24.4-25.099, 28.000-29.999, and 50.000-54.000MHz.

In terms of reception, the IC-7800 MKII offers general coverage from 0.030-60.000MHz. It features an Oven Controlled Crystal Oscillator (OCXO) that ensures stability within ±0.05ppm at temperatures ranging from 0° to 50°C. The transceiver also includes two types of preamps, a built-in receive audio equalizer with separate bass and treble controls, and a 7-step attenuator.

For connectivity, the IC-7800 MKII provides external speaker connectors for the main and sub-receiver, as well as BNC-type Rx In/Out connectors for the receiver antenna or external attenuator. It also has a separate pre-amp and mixer for 6m, optical digital audio input/output for PC connection, and a large 7-inch colour TFT display with a real-time spectrum scope.

Other notable features of the IC-7800 MKII include 101 memory channels with 10-character alphanumeric display, various scanning modes, analogue metering displayed on the colour LCD, digital twin PBT (Passband tuning), notch functions (manual or automatic), variable level Noise Reduction, adjustable Noise Blanker, CTCSS encode/decode, built-in voice synthesizer, digital voice recorder, UTC/Local clock and timer function, and RTTY/PSK31 operation without a PC connection.

The transceiver also comes with a high-speed auto ATU built-in for a frequency range of 1.8-54MHz, multiple antenna connectors (SO-239 x 4, BNC x2), CI-V interface capability, and a power requirement of 85-265V AC with a current consumption of Tx: max 800VA, Rx: Stand-by 200VA, Max Audio: 210VA. It has an audio output of >2.6W (8 Ohms) and dimensions of 424 x 149 x 435mm, weighing 25kg.

Optional accessories include the CT-17 CI-V converter, LD-T17 Icom TFT 17-inch monitor, HM-36 Hand microphone, SM-20 Deluxe desktop microphone, and SP-20 External speaker.
