Second Hand Yaesu FT-897 Portable Transceiver 1
Click the image to enlarge

Second Hand Radio equipment

Second Hand Yaesu FT-897 Portable Transceiver

Good used condition for its age, complete with power lead and microphone! - Wide banded for 11m use!

£0.00
(£0.00 exc. VAT)
£599.00
(£599.00 exc. VAT)
Fast uk delivery
Worldwide delivery
Out of Stock
0 Reward points
Product code: SH-FT-897
Download a pdf document for Second Hand Yaesu FT-897 Portable Transceiver

Want to be notified when this product is back in stock? Complete the form below and we'll send you an email when it is.

Finance Available

Radioworld now offer finance through our partners Close Brothers.

Add the item to your basket in the normal way and at checkout choose to make payment via Finance. You’ll then be taken through to our partners Pay4Later to make your finance application.

Item CostFinance OptionDepositMonthly PaymentsTotal Cost
£599.00
12 Months 14.9% APR
£59.90
£51.62
£679.33
£599.00
18 Months 14.9% APR
£59.90
£34.41
£679.33
£599.00
24 Months 14.9% APR
£59.90
£25.81
£679.33
£599.00
36 Months 14.9% APR
£59.90
£17.21
£679.33
£599.00
48 Months 14.9% APR
£59.90
£12.90
£679.33
£599.00
12 Months 19.5% APR
£59.90
£53.69
£704.12
£599.00
18 Months 19.5% APR
£59.90
£35.79
£704.12
£599.00
24 Months 19.5% APR
£59.90
£26.84
£704.12
£599.00
36 Months 19.5% APR
£59.90
£17.90
£704.12
£599.00
48 Months 19.5% APR
£59.90
£13.42
£704.12

Click here to recommend this product to a friend

Recommend a friend

Second Hand Yaesu FT-897 Portable Transceiver 1

Second Hand Yaesu FT-897 Portable Transceiver


American hams got their first look at the new Yaesu FT-897 at the 2002 Dayton Hamvention. It is the world's first multi-mode high-power base/mobile transceiver designed to fitted with internal batteries (optional) for portable use. The coverage is HF 160 to 10 meters plus 50/144/430 MHz VHF/UHF. Receive is 0.1-56, 76-108, 118-164 and 420-470 MHz. It is ideal for home, vacation, emergency, rescue, DX-pedition or VHF/UHF rover operation. With optional items the FT-897 system can be configured for mobile, base or portable use.

The large multi-color display can be programmed to show different colors on each band, mode, memory group or event to track signal strength by color! There are two antenna connectors HF/50 and 144/430. 7.9 x 3.2 x 10.3 inches (200x80x263 mm). The FT-897 comes with a MH-31B8 hand mic and power cord.

Features

* TX Frequency Coverage: 160-10 Meters, 50 MHz, 144 MHz, 430-450 MHz, plus Alaska Emergency Chan. (5167.5 kHz). * RX Frequency Coverage: 100 kHz-56 MHz; 76-154 MHz; 420 - 470 MHz. (Exact frequency range may be slightly different) * Power Output: 100 watts HF-6M, 50 watts 2 M, 20 watts 70 cm. (20 watts on battery) * Operating Modes: USB, LSB, CW, AM, FM, W-FM, Digital (AFSK), Packet (1200/9600 FM). * Digital Modes: RTTY, PSK31-U, PSK31-L, and User defined USB/LSB (SSTV, Pactor, etc.). * U.S. Weather Band reception. * Built-in 3-Message Memory Keyer. * Multi-Color LCD Multi-function Display. * Bar-Graph Metering of Power Output, ALC, SWR, Modulation. * Optional Narrow CW and SSB Filters. * AGC Fast-Slow-Auto-Off Selection. * RF Gain/Squelch Control/IF Control. * Built-in Noise Blanker. * AM and FM broadcast reception. * Dual VFOs, Split Capability, IF Shift, and R.I.T. ("Clarifier"). * Wide/Narrow FM Selection. * AM Aircraft Reception. * Dedicated SSB-based Digital Mode for PSK31 on USB/LSB, AFSK RTTY, etc. * Built-in CW Electronic Keyer and Semi-Break-In. * Transverter Interface Jack. * Built-in VOX. * Carry Handle. * Built-in CTCSS and DCS. * ARTS™ (Auto-Range Transponder System). * Smart Search™ Automatic Memory Loading System. * Spectrum Scope. * 200 Regular Memories, plus Home Channels and Band-Limit (PMS) Memories. * Alpha-Numeric Labeling of Memory Channels. * Automatic Power-Off (APO) and Tx Time-Out Timer (TOT) Features. * CAT System Computer Control Capability Cloning Capability.

General Frequency Range Receive:

Frequency Range Transmit:

(Amateur bands only)

100 kHz-56 MHz 76 MHz-108 MHz 118 MHz-164 MHz 420-470 MHz

160-6 Meters 2 Meters 70 Centimeters 5.1675 MHz Alaska Emergency Frequency (USA only)

Emission Modes:A1 (CW), A3 (AM), A3J (LSB/USB), F3 (FM), F1 (9600 bps packet), F2 (1200 bps packet) Synthesizer Steps (Min.):10 Hz (CW/SSB), 100 Hz (AM/FM/WFM) Antenna Impedance: 50 Ohms, Unbalanced (Type M [SO239])

Operating Temperature Range:-10° C to +60° C (+14° F to +140° F) Frequency Stability:± 4 ppm from 1 min. to 60 min. after power on. 25° C: 1 ppm/hour Supply Voltage:Normal: 13.8 VDC ±15 %, Negative Ground

Optional: FNB-78 (Ni-MH Battery Pack): 13.2 VDC Current Consumption: Squelched: 600 mA (Approx.) Receive: 1 A Transmit: 22 A

Case Size:7.9 x 3.2 x 10.2 inches (200x80x262 mm) Weight (Approx.):8.6 lbs. 3.9 kg (without Ni-MH battery, antenna or microphone)

Transmitter RF Power Output:100/50/20 W SSB/CW/FM Modulation Types: SSB: Balanced Modulator AM: Early Stage (Low Level) FM: Variable Reactance

FM Maximum Deviation:±5 kHz (FM-N: ±2.5 kHz) Spurious Radiation:-50 dB (1.8-29.7 MHz) -60 dB (50/144/430 MHz) Carrier Suppression:>40 dB Opposite Sideband Suppression: >50 dB

SSB Frequency Response:400 Hz-2600 Hz (-6 dB) Microphone Impedance:200-10k Ohms (Nominal: 600 Ohms)

Receiver Circuit Type:Double-Conversion Superheterodyne Intermediate Frequencies: 1st : 68.33 MHz (SSB/CW/AM/FM);10.7 MHz (WFM) 2nd: 455 kHz

Sensitivity SSB/CW AM FM 100 kHz-500 kHz - - - 500 kHz-1.8 MHz - 32 µV - 1.8 MHz-28 MHz 0.2 µV 2 µV - 28 MHz-30 MHz 0.2 µV 2 µV 0.5 µV 50 MHz-54 MHz 0.125 µV 1 µV 0.2 µV 144/430 MHz 0.125 µV - 0.2 µV (SSB/CW/AM = 10 dB S/N, FM = 12 dB SINAD)

Squelch Sensitivity SSB/CW/AM FM 1.8 MHz-28 MHz 2.5 µV - 28 MHz-30 MHz 2.5 µV 0.32 µV 50 MHz-54 MHz 1 µV 0.16 µV 144/430 MHz 0.5 µV 0.16 µV (IPO, ATT off)

Image Rejection: HF/50 MHz: 70 dB 144/430 MHz: 60 dB IF Rejection:60 dB Selectivity (-6/-60 dB):SSB/CW: 2.2 kHz/4.5 kHz AM: 6 kHz/20 kHz FM: 15 kHz/30 kHz FM-N: 9 kHz/25 kHz SSB (option):2.3 kHz/4.7 kHz (-66 dB) CW (option):500 Hz/2.0 kHz AF Output:2.5 W (8 Ohms, 10% THD or less) AF Output Impedance:4-16 Ohms

Good used condition for its age, complete with power lead and microphone! - Wide banded for 11m use!
