Alinco DX-10 28MHz All Mode Mobile Transceiver

The Alinco DX-10 is a versatile 10-meter mobile transceiver designed for amateur radio enthusiasts seeking performance, flexibility, and value. Covering a wide frequency range of 28.000 – 29.700 MHz, and PC programmable from 25 – 29.700 MHz (for export users), this compact unit supports AM, FM, USB, LSB, and CW modes, making it suitable for both mobile and base station use.

Key Features:

• Frequency Range: 28.000 – 29.700 MHz (PC programmable 25 – 29.700 MHz)

• Modes: AM, FM, USB, LSB, CW

• Power Output:

  • 1–12W (FM/CW)

  • 0–25W (USB/LSB)

• Memory Channels:

  • 40 channels per band standard

  • Up to 60 channels per band with optional software

• Current Consumption:

  • TX: Max 6A

  • RX: Max 800mA / 400mA (squelched)

Display & Controls:

• Multi-colour backlit LCD with 7 selectable colours + rainbow mode

• LCD S-meter, RF gain, clarifier, SWR meter

• Noise Blanker (NB) and Automatic Noise Limiter (ANL)

• Hi-cut RX tone filter and CW sidetone (300Hz–3kHz)

Connectivity & Programming:

• PC programmable via optional ERW-10 USB cable and software disk

• External speaker socket

• CW key jack

• Dual watch and scanning functions

Dimensions & Build:

• Size: 173 × 51 × 238 mm

• Weight: 1.5 kg

• Power Supply: 13.8 VDC ±15%

• Connectors:

  • 6-pin microphone connector

  • PL-259 (SO239) antenna connector

Additional Features:

• +10 KHz offset button

• Keypad lock

• Programmable time-out timer

• Over-voltage protection

• Public address (PA) facility

• Factory reset function.
