Diamond HFV-40 | Rotary Dipole antenna
Diamond HFV-40 | Rotary Dipole antenna
- Home
- Diamond HFV-40 | Rotary Dipole antenna
Diamond Antenna Corporation | Products
Diamond HFV-40 | Rotary Dipole antenna
Finance Available
Radioworld now offer finance through our partners Close Brothers.
Add the item to your basket in the normal way and at checkout choose to make payment via Finance. You’ll then be taken through to our partners Pay4Later to make your finance application.
Item Cost | Finance Option | Deposit | Monthly Payments | Total Cost |
---|---|---|---|---|
£259.96
|
12 Months 14.9% APR
|
£26.00
|
£22.40
|
£294.82
|
£259.96
|
18 Months 14.9% APR
|
£26.00
|
£14.93
|
£294.82
|
£259.96
|
24 Months 14.9% APR
|
£26.00
|
£11.20
|
£294.82
|
£259.96
|
36 Months 14.9% APR
|
£26.00
|
£7.47
|
£294.82
|
£259.96
|
48 Months 14.9% APR
|
£26.00
|
£5.60
|
£294.82
|
£259.96
|
12 Months 19.5% APR
|
£26.00
|
£23.30
|
£305.58
|
£259.96
|
18 Months 19.5% APR
|
£26.00
|
£15.53
|
£305.58
|
£259.96
|
24 Months 19.5% APR
|
£26.00
|
£11.65
|
£305.58
|
£259.96
|
36 Months 19.5% APR
|
£26.00
|
£7.77
|
£305.58
|
£259.96
|
48 Months 19.5% APR
|
£26.00
|
£5.82
|
£305.58
|
The diamond hfv-40 is a compact rotary dipole for 40m, as usual, built-in excellent manufacturing quality by diamond. The antenna is designed as a shortened dipole. Due to the precise alignment possibilities of the dipole the minimum SWR position can be tuned very effectively to the required band portion. As with all shortened antennas, the useable bandwidth is limited, you have to re-align the antenna when changing the operating frequency. The useable bandwidth without a tuner is approx. 30 kHz on 40m. The small packing size of only 102cm makes the hfv-40 also suitable as a vacation antenna or for portable field day operations. Installed, the dipole has a length of approx. 460cm. Due to to the v shape of the antenna the turning radius is only 165 cm. The weight of the antenna is only 2.3 kg, the connector is pl type, a cable is not included. The included mast clamp is suitable for masts from 30 to 62mm in diameter.
