The PWRguard Plus Automatic safety switch turns off if voltage exceeds 15 volts or drops below 11.0 volts, turns back on when the voltage is in safe operating range, Momentary voltage dips below 11.0 volts are ignored to prevent false tripping while transmitting Programming of custom trip limits available, contact sales for details, Rated for 40 amps maximum while transmitting, 30 amps continuous duty,
Soft turn-on/turn-off solid-state switch protects the radio and reduces in-rush current...no relay contact bounce!
Indicator LEDs and audible alarms notify the user when the safety switch turns the power off. The buzzer may be disabled by the user
External sense input can be wired to a switch or low voltage (3-5 volt) DC input. May be used for Keyswitch to prevent rig use during antenna repairs or when unattended.
Cut power based on a sensor input such as a water alarm.
Power up based on a sensor such as a light detector or low current switch.

Uses Anderson Powerpole® connectors
Dimensions: 1.25" H x 4.5" W x 2.75" D

Please click here for more information on Powerpole® Connectors.
