RIGblaster Duo USB Complete RB/DU/CUSB
Click the image to enlarge

West mountain radio Products

West Mountain Adaptor RIGblaster Duo USB Complete RB/DU/CUSB - Dual Radio Operation, complete station integration console.

£0.00
(£0.00 exc. VAT)
£289.96
(£241.63 exc. VAT)
Fast uk delivery
Worldwide delivery
Qty:
0 Reward points
Product code: 58001-952
Download a pdf document for West Mountain Adaptor RIGblaster Duo USB Complete RB/DU/CUSB - Dual Radio Operation, complete station integration console.
Finance available on baskets over £250 view details

Want to be notified when this product is back in stock? Complete the form below and we'll send you an email when it is.

Finance Available

Radioworld now offer finance through our partners Close Brothers.

Add the item to your basket in the normal way and at checkout choose to make payment via Finance. You’ll then be taken through to our partners Pay4Later to make your finance application.

Item CostFinance OptionDepositMonthly PaymentsTotal Cost
£289.96
12 Months 14.9% APR
£29.00
£24.99
£328.84
£289.96
18 Months 14.9% APR
£29.00
£16.66
£328.84
£289.96
24 Months 14.9% APR
£29.00
£12.49
£328.84
£289.96
36 Months 14.9% APR
£29.00
£8.33
£328.84
£289.96
48 Months 14.9% APR
£29.00
£6.25
£328.84
£289.96
12 Months 19.5% APR
£29.00
£25.99
£340.84
£289.96
18 Months 19.5% APR
£29.00
£17.32
£340.84
£289.96
24 Months 19.5% APR
£29.00
£12.99
£340.84
£289.96
36 Months 19.5% APR
£29.00
£8.66
£340.84
£289.96
48 Months 19.5% APR
£29.00
£6.50
£340.84

RIGblaster Duo USB Complete RB/DU/CUSB, Capabilities: Dual Radio Operation, complete station integration console that allows you to conveniently monitor and control audio almost any way you wish and also selects transmit so that you may use your best microphone, headphones, and speakers on two different radios, Makes your station neater, better, and more efficient, and easier to operate, Cleans up clutter and eliminates tangled mic. and headphone cords, Compatible with All Manufacturers' Radios,

Can be used with almost any make or model microphone and most any two, make or model radios no matter what brand

Any radio that has an 8 pin round screw-on microphone connector, Any radio that has an RJ45 modular telephone-style connector

Any radio with RJ25 6 wire microphone connector with the purchase of an optional FT100 style 6 wire modular mic. cable

Any radio with 4 pin round microphone connector with the purchase of an optional 4 pin mic cable,
Computer Interface, Comes with a built-in dual USB to serial converter to use two amateur radio software applications at the same time
Built-in Rig Control,

•Works with any radio that requires a special TTL level converter that does not hook directly to an RS232 port

•Dual CI-V or TTL level CAT rig control to control two different radios via either virtual COM port,

•Tested with Icom and Yaesu, compatible with Ten-Tec,
True Keyed CW,

•Dual isolated CW keying and dual FSK (MMTTY EXTFSK) outputs key both radios via computer software that can operate with either virtual COM port,

•Separate CW and FSK Keying jacks, Maximum Mic/Keying/Audio Flexibility,

•Enables use of 1 mic, 1 pair of headphones, 1 pair of speakers with two radios,

•Two built-in 3 watts per channel stereo amplifiers let you monitor everything; two radios and the computer, with a single pair of amplified or un-amplified stereo speakers and/or a pair of headphones,

•Versatile receive audio selection that is modeled after the function and ergonomics of an aircraft audio panel to monitor your choice of any combination of radio A, B, and computer on headphones and/or speakers. Each radio can be internally configured for your choice stereo dual receive, dual-mono or left or right,

•Computer audio input can be internally configured to left and right for radio A and B or can, instead, track what is being monitored

•External 12 volt trigger outputs for the optional station on/off control,

•External trigger outputs for "radio ready to transmit" LED indicators or other control functions.
Construction,

•Assembled in the USA to IPC-610 manufacturing standards,

•Printed circuit board uses FR4 material, double-sided, plated through holes, solder mask over bare copper, silk-screened

•Enclosure: .062 aluminum, polyurethane painted, silk screen labeling front and back,

•3M Bumpon™ protective feet and 3M™ adhesive pads are provided for mounting,

•Toggle switches: 50,000 make and break cycles, 2 amps 250 VAC,
•Stainless steel hardware throughout including PEM™ threaded mounting standoffs,

Contents: Two Radio - Station Integration Console,
•DC power cord with Powerpole connector,
•(2) Microphone Cables - 3 ft RJ45 to 8 pin screw on,
•Microphone Cable - 3 ft RJ45 to RJ45,
•USB A to B Interface Cable,
•(8) 1/8 in/3.5mm Stereo Mini Plug 6 ft Patch Cords,
•Owners Manual,
•CD-ROM,
•Accessory Kit,
•(12) White Wire Jumpers,
•(2) 1/8" Mini to 1/4" Adapter.
