MFJ-17758 80/40 Meter Dipole Antenna
Click the image to enlarge

MFJ Enterprises | Products

MFJ-17758 80/40 Meter Dipole Antenna

£0.00
(£0.00 exc. VAT)
£99.95
(£83.29 exc. VAT)
Qty:
0 Reward points
Product code: MFJ-17758
Download a pdf document for MFJ-17758 80/40 Meter Dipole Antenna
Finance available on baskets over £250 view details

Want to be notified when this product is back in stock? Complete the form below and we'll send you an email when it is.

Finance Available

Radioworld now offer finance through our partners Close Brothers.

Add the item to your basket in the normal way and at checkout choose to make payment via Finance. You’ll then be taken through to our partners Pay4Later to make your finance application.

Item CostFinance OptionDepositMonthly PaymentsTotal Cost
£99.95
12 Months 14.9% APR
£9.99
£8.61
£113.35
£99.95
18 Months 14.9% APR
£9.99
£5.74
£113.35
£99.95
24 Months 14.9% APR
£9.99
£4.31
£113.35
£99.95
36 Months 14.9% APR
£9.99
£2.87
£113.35
£99.95
48 Months 14.9% APR
£9.99
£2.15
£113.35
£99.95
12 Months 19.5% APR
£9.99
£8.96
£117.49
£99.95
18 Months 19.5% APR
£9.99
£5.97
£117.49
£99.95
24 Months 19.5% APR
£9.99
£4.48
£117.49
£99.95
36 Months 19.5% APR
£9.99
£2.99
£117.49
£99.95
48 Months 19.5% APR
£9.99
£2.24
£117.49

The MFJ-17758 is a two band, 80- and 40-Meter center-fed dipole antenna capable of handling 1500 watts. Its total length is 85 feet. Each side of the dipole is broken up by a coil that presents a high impedance at 40 meters and acts as a loading coil on 80 meters, allowing the antenna to resonate on 80 meters even though it is physically shorter than a half-wavelength (approximately 130 feet at 3.7 MHz).

Because this antenna acts as a dipole on both bands its impedance is around 50 to 70 ohms, permitting it to be fed with coaxial cable. The use of a current balun between the coaxial feedline and the antenna is highly recommended, to help prevent stray RF from traveling down the coaxial cable?s outer shield. This is easily accomplished with an MFJ-915 RF Isolator and a ?double male? coaxial connector (MFJ-7702).
