BWD‑180N – Barker & Williamson Commercial Folded HF Dipole Antenna


Trustpilot

The BWD‑180N is a high‑performance commercial folded dipole designed to deliver exceptionally broad HF coverage with minimal SWR and unmatched receive quietness. Engineered for demanding commercial and amateur applications, it provides SWR below 2:1 across the entire HF band and remains below 3:1 up to 60 MHz, eliminating the need for an antenna tuner on HF.

Constructed from 14‑strand stainless‑steel wire and supplied fully assembled, the BWD‑180N is built for long‑term reliability in harsh environments. Its 50‑ohm N‑type feed, rugged centre assembly, and flexible installation options make it suitable for fixed stations, emergency deployments, and commercial monitoring sites.

The antenna can be installed as a flat‑top dipole, inverted‑V, or sloper, with shorter versions capable of self‑support. For the full 180‑foot model, a three‑pole mast system is required (MK114 or MK112).


Technical Specification

SpecificationDetails
ModelBWD‑180N
Antenna TypeFolded HF dipole
Frequency CoverageEntire HF range
SWR (HF)Less than 2:1
SWR (30–60 MHz)Less than 3:1
Power Rating1 kW PEP SSB/CW ICAS
Wire Material14‑strand stainless steel
Input Impedance50 ohms
ConnectorN‑type
Noise CharacteristicsExtremely low noise for superior reception
Tuner RequirementNo tuner required on HF
AssemblyFully assembled, ready to install
Installation OptionsInverted‑V, flat‑top, sloper
Self‑Support90 ft and shorter models may self‑support
Mast RequirementsThree‑pole system required for 180 ft version (MK114 or MK112)
