The FRG-7700 features high sensitivity, excellent selectivity, digital plus analogue display of the operating frequency, and a built-in digital quartz clock that can be programmed to turn the receiver on and off. A snooze timer is included in the clock feature. The timer may also be used to control peripheral equipment, such as a tape recorder, for unattended recording of programs you might otherwise miss because you must be away from your station.

Top performance features include a highly effective noise blanker, a selectable fast/slow AGC (Automatic Gain Control) circuit, an audio filter that can be adjusted to improve interference rejection, an easy-to-read S-meter, and two RF attenuators (one fixed and one continuously adjustable) for operation under extreme signal conditions. For FM operation, a squelch control will silence the receiver until a signal is received. Convenient interface jacks for tape recorder control, audio output to an external speaker or tape recorder, receiver muting, and headphone listening make the FRG-7700 truly the most versatile receiver available to shortwave listeners worldwide.

Frequency Range: 150 kHz - 29.999 MHz (30 bands)

Modes: AM, SSB (USB, LSB), CW, FM

Antenna Impedance:

0.15 MHz - 2 MHz BC 500Ω (Unbalanced)

2 MHz - 29.999 MHz, SW/BC 50Ω (Unbalanced)

Audio Output: 1.5 Watts (8Ω, 10% THD)

Speaker Impedance: 8Ω, 4-16Ω for external speaker or headphone

Power Requirement: 100/120/220/240 volts, AC 50/60 Hz

Power Consumption: Stand by-AC 10 VA, ON-AC 33 VA

Dimensions: (WHD) 334 x 129 x 225mm

Weight: Approx. 6 kg

Please note that used equipment may show slight wear or imperfections, which is normal. Additionally, VAT does not apply to used equipment.
