Diamond Antenna – High‑Performance, Durable Communication Solution

Diamond X200A Dual Band 2m 70cm Base Antenna 200W High Gain

£0.00
(£0.00 exc. VAT)
£109.96
(£91.63 exc. VAT) + £5.00
Please note that there is an extra charge for deliveries exceeding 1.0 meter.
Fast uk delivery
Worldwide delivery
In Stock
Dual-band 144–148 MHz and 435–450 MHz antenna offering 6.0 dB / 8.0 dB gain with a strong 200-watt power handling capability for reliable VHF and UHF performance.
Qty:
ADD TO WISHLIST
109 Reward points
Product code: X-200A
Download a pdf document for Diamond X200A Dual Band 2m 70cm Base Antenna 200W High Gain

Want to be notified when this product is back in stock? Complete the form below and we'll send you an email when it is.

Sorry!

This product is currently out of stock, there is no expected lead time until it is back in stock, but you can still order anyway.

Qty:

Finance Available

Radioworld now offer finance through our partners Close Brothers.

Add the item to your basket in the normal way and at checkout choose to make payment via Finance. You’ll then be taken through to our partners Pay4Later to make your finance application.

Item CostFinance OptionDepositMonthly PaymentsTotal Cost
£109.96
12 Months 14.9% APR
£11.00
£9.48
£124.70
£109.96
18 Months 14.9% APR
£11.00
£6.32
£124.70
£109.96
24 Months 14.9% APR
£11.00
£4.74
£124.70
£109.96
36 Months 14.9% APR
£11.00
£3.16
£124.70
£109.96
48 Months 14.9% APR
£11.00
£2.37
£124.70
£109.96
12 Months 19.5% APR
£11.00
£9.85
£129.25
£109.96
18 Months 19.5% APR
£11.00
£6.57
£129.25
£109.96
24 Months 19.5% APR
£11.00
£4.93
£129.25
£109.96
36 Months 19.5% APR
£11.00
£3.28
£129.25
£109.96
48 Months 19.5% APR
£11.00
£2.46
£129.25

Click here to recommend this product to a friend

Recommend a friend

Diamond X200A dual band base antenna 2m 70cm front view

Diamond X200A Dual Band 2m 70cm Base Antenna 200W High Gain


Trustpilot

The Diamond X200A Dual-Band Base Antenna is a high-performance VHF/UHF base station antenna designed for the 2 metre (144–148 MHz) and 70 cm (435–450 MHz) amateur radio bands. Built with heavy-duty fiberglass sections and quality stainless steel hardware, the X200A delivers strong gain of 6.0 dB on 2 m and 8.0 dB on 70 cm with a maximum power handling of 200 W, making it suitable for base or repeater duty. Its overlapping outer shells and waterproof design provide excellent durability and weather resistance, while factory adjustment means no tuning is required prior to use. DC grounded for added protection, this antenna is ideal for HF/UHF communications and amateur radio installations.

Key Features

  • Dual-band 2 m/70 cm base station antenna

  • Gain: 6.0 dB on 2 m and 8.0 dB on 70 cm

  • Maximum power handling up to 200 W

  • Heavy-duty fiberglass construction

  • Waterproof joint couplings and stainless hardware

  • Factory adjusted for ready use — no tuning required

  • DC grounded for lightning protection

  • SO-239 (UHF) style connector

  • Robust performance for VHF/UHF communications and amateur radio operations

Technical Specifications

  • Frequency Coverage: 144–148 MHz (2 m), 435–450 MHz (70 cm)

  • Gain: 6.0 dB (2 m), 8.0 dB (70 cm)

  • Power Handling: 200 W

  • Impedance: 50 Ω

  • VSWR: < 1.5:1

  • Wind Resistance: Rated to 50 m/s

  • Connector: UHF Female / SO-239

  • Length: Approx. 2.5 m

  • Construction: Fiberglass with stainless steel hardware
