The Flex-6700r Signature Series radios from Flex Radio bring a wealth of new capabilities to the amateur radio community. These radios feature direct digital sampling reception, transmission, and networking, all powered by the advanced reusable framework of SmartSDR.
One of the standout features of the Flex-6000 Signature Series is its plug-and-play installation. No drivers or interface cards are required. Simply connect the radio to an antenna, power supply, and network, load the SmartSDR software on your existing PC, and you're ready to operate.
The FLEX-6700R receiver is equipped with two independent, synchronous Analog Devices AD9467 16-bit 245.76 Msps analog to digital converters (ADC). This allows for direct digitization of the RF spectrum, providing exceptional performance.
With the FLEX-6700R, you can create up to 8 independent Slice Receivers, covering a frequency range from 0.03 MHz to 77 MHz and 135 MHz to 165 MHz. Each Slice Receiver can display up to 384 kHz of spectral information, giving you a comprehensive view of the RF environment.
The Flex-6000 Signature Series also boasts impressive digital signal processing power. The FLEX-6700R delivers 317 billion multiply-accumulate operations per second (GMACS) and 121 billion floating point operations per second (GFLOPS), ensuring top-notch performance.
For those looking for precise timing, the Flex-6000 Signature Series offers an optional built-in GPS Disciplined Oscillator (GPSDO). This feature sets it apart from other amateur radio products on the market.
In terms of specifications, the Flex-6000 Signature Series offers two USB 2.0 ports, and multiple modes including USB, LSB, CW, RTTY, AM, FM, and BNC antenna connectors. The antenna impedance is 50 Ohm unbalanced, and the power supply requirements are 25-264V AC; 47-63Hz; 20W. The dimensions of the radio are 3330 x 305 x 102 mm, and it weighs 5kg. The wideband frequency coverage is from 0.30 to 77 MHz and 135 to 165 MHz, with amateur band preselector coverage from 160 to 6m (except 60m).
Flex 6700R (Receiver) - The FLEX-6700R receiver allows creation of up to 8 independent Slice Receivers providing reception from 0.03 MHz to 77 MHz and 135 MHz to 165MHz. Each Slice Receiver can provide independent spectral display of up to 384 kHz.
Flex 6700 (Transceiver) - The FLEX-6700 incorporates two independent, synchronous Analog Devices AD9467 16-bit 245.76 Msps (Mega samples per second) analog to digital converters (ADC) that allow direct digitization of the RF spectrum.
