Simple and practical PC control software, you can export Touchstone (snp) files for various radio design and simulation software through PC software. The improved frequency algorithm can use the odd harmonic extension of si5351 to support the measurement frequency up to 900MHz.

The metal shield is designed to reduce the external interference and improve the measurement accuracy. The 50535-300MHz frequency range of the si5351 direct output provides better than 70dB dynamic. The extended 300M-600MHz band provides better than 60dB of dynamics, and the 600M-900M band is better than 50dB of dynamics.

This DIY product provides perfect vector measurement capabilities in the size of a credit card. It includes a 2.8-inch Press screen and a 500mAh battery, which can be used offline for 2 hours.

For longer measurements, please connect an external power supply or contact me to make a larger battery version. The TX/RX method can measure the complete S11 and S21 parameters. If you need to obtain S12 and S22, manually replace the transceiver port wiring.

Basic performance:

PCB: 54mm x 85.5mm x 11mm (without connectors, switches)

Measurement frequency: 50KHz ~ 300MHz (50KHz -900MHz, enable extended firmware)

RF output: -13dbm (maximum -9dbm)

Measurement range: 70dB (50kHz-300MHz), 60dB (300M-600MHz), 50dB (600M-900MHz) enable extended firmware);

USB interface: USB type-C communication mode: CDC (serial)

Power: USB 5V 120mA, built-in 300mAh or 500mAh battery, maximum charging current 0.8A(without battery)

Material:Metal

colour: black

Package Contents:

1 * NanoVNA host (without 500mAh battery)

1 * USB Type-C data cable

2 * 30mm SMA male to male RG174 RF cable

1 * SMA simple calibration kit

1 * SMA female-to-female connector

Only the above package content and other products are not included.

Note: Light shooting and different displays may cause the colour of the item in the picture to be a little different from the real thing. The measurement allowed error is +/- 1-3cm.
