This high efficiency AC-DC power converter delivers a regulated output DC voltage of 13.8 Volts at 23 Amps, compatible with AC inputs of 115 or 230 Volts and frequencies of 60-50 Hz. Crafted explicitly for land mobile radio applications, these switch-mode DC power supplies offer clean and reliable power, boasting strong RFI suppression. The unit includes a detachable power supply cord with a "SCHUKO" plug and features protective measures against over-current, short-circuit, over-voltage, and over-temperature incidents. Moreover, the power supply adheres to EN60950 safety standards and various EMI/EMC standards.

The SEC-1225G model operates with an input voltage range of 115-230 VAC, providing a stable output voltage of 13.8 VDC at 23 Amps. With dimensions measuring 190 x 180 x 60 mm, this power converter is compact and efficient. The unit weighs 1.75 Kgs and features a fuse rating of 4 Amps, ensuring safe and reliable operation. Ideal for various applications requiring a robust and regulated power supply, the SEC-1225G model stands out for its performance and adherence to safety and EMI/EMC standards.

Need the radio cabinet? Please click here or see our 'related products' below!
