Heil HM-12 amateur radio desk microphone close-up

Heil Sound HM-12 Dynamic Cardioid Microphone – 4-Pin XLR Amateur Radio Desk Mic | Radioworld UK


The Heil Sound HM-12 is a purpose-built dynamic cardioid microphone designed specifically for amateur radio communications.
Equipped with Heil’s Genesis™ full-range dynamic element, the HM-12 provides high output, clear articulation, and excellent background noise rejection for superior on-air voice quality.

This microphone features the classic Heil +4 dB presence boost at 2 kHz, ensuring crisp, intelligible audio that cuts through pileups while maintaining a smooth low-end response.
Its –35 dB rear rejection and internal shock-mounted element minimize room and handling noise.

The HM-12 is fitted with a 4-pin XLR connector — with the PTT (Push-to-Talk) switch wired to pins 3 & 4 and the audio output on pins 1 & 2 — making it fully compatible with Heil CC-1 adapter cables for all major transceiver brands.
A built-in foam windscreen and included 5/8"-27 mic clip make it ready to mount on Heil booms or desk stands.


Key Features

  • Designed specifically for amateur radio transmit audio

  • Dynamic cardioid element with full-range “Genesis” response

  • Signature +4 dB boost at 2 kHz for enhanced articulation

  • Exceptional rear rejection (–35 dB) reduces ambient noise

  • 4-pin XLR output connector with built-in PTT switch

  • Works with Heil CC-1 cables for Icom, Yaesu, Kenwood, Ten-Tec, Collins & others

  • Internal shock mount and foam windscreen

  • Includes 5/8"-27 microphone clip for Heil stands and booms

  • Rugged metal construction with satin black finish

  • Made in the USA


Technical Specifications

SpecificationDetails
ModelHM-12
TypeDynamic, cardioid pattern
Generating ElementGenesis™ moving-coil dynamic
Frequency Response80 Hz – 14 kHz
Output Level–55 dB
Impedance1 kΩ
Rear Rejection–35 dB
Connector4-pin XLR (Pins 1-2 Audio, Pins 3-4 PTT)
FinishSatin black
Weight8.8 oz (≈ 250 g)
Included AccessoriesFoam windscreen, 5/8"-27 mic clip
ManufacturerHeil Sound, USA
